POSITIONING.
MEASURE. CONTROL. MOVE.

Product development. Manufacturing. Quality testing.
Individually for our customers. Tailored to each industry.

Product development. Manufacturing. Quality testing. Individually for our customers. Tailored to each industry

Increasing expectations regarding the efficiency and effectiveness of the samples to be examined are growing at a rapid pace. In order to meet these requirements, the equipment and applications used are also becoming more precise, faster and more dynamic. Measurements “on the fly” with increasingly high acceleration values and consideration of the resulting dynamic effects require a deep understanding of the motion sequences and couplings between the individual components. A high degree of integration in the end devices of the samples under investigation and a deep understanding of the end applications are prerequisites here. In close dialogue with our customers, we jointly develop the best solution for the respective application. The close dialogue with the user often creates the breakthrough to innovative and groundbreaking products, which are only possible through the willingness to openly exchange ideas. Off-the-shelf catalogue products are the wrong answer here, because we have often found: There is no off-the-peg.

PRODUCT DEVELOPMENT

produktentwicklung

All electronics and software developments are created in our own research and development department. Experienced, curious and highly motivated employees are always looking for new challenges – with the aim of developing the best products on the market.

MANUFACTURING

fertigung

In order to be able to react quickly and flexibly to all customer requirements, we have an extensive stock of raw materials: granite as a solid foundation, aluminium alloys for normally loaded components and trim parts, titanium for particularly demanding components and high-tech materials such as carbon fibre composite.

QUALITY ASSURANCE

qualitaetssicherung

Quality is an integral part of our work. Because only uncompromising quality in all phases of development, design and production ensures that our products perfectly withstand the conditions to which they are exposed at all times.

We develop and produce linear axis, positioning axis and complete mechatronic positioning systems for your application: no matter if microscope table or Gantry System for material analysis. Any precise positioning system is made of our core products added by decades of experience in system design and motion control technology.
To the products

If your application requires precision and high resolution, then the measurement system developed in-house by ITK are the perfect fit. Even in dirty or harsh environments the incremental or absolute  measurement systems by ITK are available as linear or rotatory solutions.
To the products

For position systems the main task is to achieve the intended position fast and precise, which requires enormous technical knowledge and experience. With almost 40 years’ experience in developing and producing high resolution controllers we are proud to say: intelligent controllers made by ITK position systems accurate and on point – even up to the nanometer.
To the products

ITK offers linear and stepper motors in different power classes. With intelligent motion controllers and our modified stepper motors extremely high resolutions are achievable. In combination with our internal motion controllers it is possible to reduce resonances to a minimum. In-house developed, patented linear motors are used in all our positioning systems, but are also available as stand alone products. Ideal for your individual application.
To the products

SYSTEMS FOR HIGH-PRECISION CONTROL & POSITIONING 

The constructive interaction of our core competences has a great
influence on the end product. Consequently, cooperation was defined as a strategic
collaboration was defined as a strategic task, and over the years a deep
understanding has been built up over the years. The result: through in-house development and production of the core components, we are able to supply highly accurate and efficient positioning systems at the highest technical level for industry and research.
not only modularly from a construction kit, but individually adapted.

Our product development – consisting of mechanical construction, analysis
and simulation, electronic and software development – is the initiator and
and the first point of contact for new developments brought to us by customers.
to us.

Our high level of vertical integration enables us to carry out the mechanical machining of the individual components, the electronic production, the final assembly of the positioning systems and the testing in-house.
positioning systems and testing are all carried out in-house.



YOU WANT TO STAY UP TO DATE?

THEN SUBSCRIBE TO OUR NEWSLETTER!

Privacy Policy*


As a newsletter subscriber you agree to our privacy policy.

Are you interested in our products?
Would you like to work with us to find a solution
for your task?
Then contact us.
We look forward to a constructive exchange!

With your request you agree to our privacy policy.

YOU WANT TO STAY UP TO DATE?

THEN SUBSCRIBE TO OUR NEWSLETTER!

Privacy Policy*


As a newsletter subscriber you agree to our privacy policy.

Are you interested in our products?
Would you like to work with us to find a solution
for your task?
Then contact us.
We look forward to a constructive exchange!

With your request you agree to our privacy policy.

Pollux OEM-Variants

Pollux OEM

Main features

• Available as built-in variants without housing

Cross Stage FCS100

Kreuztische

Technical Data

Parameter

Unit

Typical performance characteristics

Repeatability

µm

0,1 … 50

Traversing speed

mm/s

0,01 … 5000

Acceleration

mm/s2

100mm/s2 … 5 g

Position resolution

nm

5 … 1000

Travel path

mm

10 … 500

LMT Microscope Stages

LMT

Technical Data

Parameter

Unit

Typical performance features

Travel speed

mm/s

0.1 … 500

Acceleration

m/s2

0.1 … 10

Repeat accuracy

µm

0.25 … 0.5

Position resolution

nm

5

Travel range

mm

50 x 50 … 205 x 205

LMP linear magnetisation machines

LMP ITK

Technical Data

Parameters

Typical performance characteristics

Scale lengths

50 - 200 mm

Materials

hard magnetic, soft magnetic

Track widths

1 - 5 mm

Number of tracks

1 - 3, several coded tracks possible

Period lengths

500 - 5000 µm

Accuracy

up to the sub-µm range (compensated)

Resolution

in the nanometre range

Writing method

digital or analogue

Software

customised operating and evaluation software

Quality inspection

scale measurement on the same system

Typical operating conditions

industrial continuous operation (24/7)

Labelling

each scale can be individually marked

Rotary Stage FRS 200

Rundtisch frs200_02

Technical Data

Parameter

Unit

Typical performance characteristics

Repeatability

arcsec

2 … 36

Axial runout

µm

3 … 10

Radial runout

µm

3 … 20

Mass to be moved

kg

5 … 10

Hollow shaft

mm

40 … 50

Diameter

mm

50 … 300

Stepper motors

Schrittmotorengruppe

Main features

We can offer you stepper motors in a wide range of performance classes and torque curves. It does not matter whether in an industrial environment in clean rooms or in a dirty environment.

  • Torque curve can be individually adapted
  • High torque
  • Stronger magnetic field achieves high dynamics with the same rotor moment of inertia
  • Motor connection adapter on request
  • Dampers at the second shaft end improve the synchronisation characteristics
  • ITK’s unique control technology greatly minimises resonance frequencies
  • Suitable for clean rooms

Alpha Torque servomotors

Alphat_Gleichstrommotoren

Key features

  • High torques over the entire speed range
  • Speed max. 10 r/s
  • Precise MR measuring system absolute measuring
  • Multiturn functionality up to max. 16,000 revolutions
  • Protection class IP65

Rotary Stage RS 180

Rundtisch rs 180

Technical Data

Parameter

Unit

Typical performance characteristics

Repeatability

arcsec

2 … 36

Axial runout

µm

3 … 10

Radial runout

µm

3 … 20

Mass to be moved

kg

5 … 10

Hollow shaft

mm

40 … 50

Diameter

mm

50 … 300

Gantry Positioning System FBS

v

Technical Data

Parameter

Unit

Typical performance characteristics

Load capacity

kg

0.5 … 5

Travel speed in X & Y

m/s

0.25 ... 1

Acceleration in X & Y

m/s2

0.5 … 10

Repeatability bidirectional

µm

≤ ±1

Positioning accuracy bidirectional

µm

≤ ±20 … ≤ ±80

Resolution

nm

500

RMP Rotary Magnetisation Machines

RMP itk

Technical Data

Parameter

Typical performance characteristics

Scale diameter

3.5 - 500 mm (standard)

Scale materials

hard magnetic, soft magnetic, elastomer and plastic bonded

Coding placement

optional radial or axial description

Number of lines

freely selectable

Number of tracks:

several coded tracks possible; reference marks (polarisation adjustable)

Repeatability:

from 5 arcsec (depending on reference measuring system and material)

Resolution

up to 0.5 arcsec

Writing method

digital or analogue

Software

customised operating and evaluation software optional

Quality inspection:

scale measurement on the same system optional

Typical conditions of use

industrial continuous operation (24/7)

Marking

each scale can be individually labelled.

Linear Stage FLS100

Lineartische

Technical Data

Parameter

Unit

Typical performance characteristics

Repeat accuracy

µm

0,1 … 50

Traversing speed

mm/s

0,01 … 5000

Acceleration

mm/s2

100mm/s2 … 5 g

Position resolution

nm

5 … 1000

Travel path

mm

10 … 10.000

Linear Stage ST9 Eco

ST9 Eco

Technical Data

Parameter

Unit

Typical performance characteristics

Repeat accuracy

µm

0,1 … 50

Traversing speed

mm/s

0,01 … 5000

Acceleration

mm/s2

100mm/s2 … 5 g

Position resolution

nm

5 … 1000

Travel path

mm

10 … 10.000

Cross Stage KS15

kl12

Technical Data

Parameter

Unit

Typical performance characteristics

Repeatability

µm

0,1 … 50

Traversing speed

mm/s

0,01 … 5000

Acceleration

mm/s2

100mm/s2 … 5 g

Position resolution

nm

5 … 1000

Travel path

mm

10 … 500

Pollux-Box

Pollux Box

Main features

  • Control and motors as separate positioning unit
  • High flexibility

Measuring systems

MR_Messtechnik_Komplett

Key features

  • Magnetically coded scales allow the use of a wide variety of components (scale carriers)
  • Incremental or absolute measuring systems for determining the position are possible
  • Position resolution of 5 nm achievable
  • OptoMag evaluation electronics provide an industry-standard output signal of 1 Vpp/ 20 µm period length. Other period lengths on request
  • Adaptation to any control system possible
  • Specially designed for use in dirty environments
  • Scale encoding is carried out very precisely with a laser interferometer
  • Customer-specific scales can be realised
  • Evaluation electronics and sensor available separately (in case of space problems) or integrated
  • Vacuum compatible

Hydra-Controllers

Hydra Start

Technical Data

Parameter

Unit

Typical performance characteristics

DC link voltage

Vac

0 … 48

Max. Phase current

A

2,5 … 50

Supported motor types

mm/s2

Linear-, Stepper-, Voice Coil- Servo-, DC-Motoren

Position resolution

nm

5 … 1000

Real-time trigger


Interface compatibility


Manual control units


Safety functions

Hydra XP – the most powerful

Hydra Xp

Main features

  • 4 axes in 1 housing
  • Power supply: 48 volts
  • Power: 1600 watts
  • Phase current: max. 50 A

Hydra RM – fits in any control cabinet

Hydra RM

Main features

  • 4 axes in 1 housing
  • Power supply: 24 V / 48 V
  • Power: 1000 watts
  • Phase current: max. 15 A

Hydra TT – Table version

Hydra Start

Main features

  • 2-axis
  • Power supply: 24 V / 48V
  • Power: 300 watts
  • Current in 2-phase operation: max. 10 A
  • Current in 3-phase operation: max. 5 A
  • Interfaces: CAN, RS232, Ethernet

Hydra CM – with compact design

Hydra CM

Main features

  • 2-axis
  • Power supply: 24 V / 48 V
  • Power: max. 500 W
  • Phase current: 10 A (24 V) / 5 A (48 V)
  • External 24 V / 48 V power supply unit
  • Suitable for mounting in control cabinet
  • Compact design enables mounting directly on positioning mechanisms

Hydra DT – with Joystick

Hydra DT

Main features

  • 2-axis
  • Power supply: 24 V / 48 V
  • Power: 150 watts
  • Phase current: max. 10 A (24V) / 5 A (48V)
  • 6 freely programmable function keys

Andromeda-Controllers

Andromeda

Technical Data

Parameter

Unit

Typical performance characteristics

DC link voltage

Vac

0 … 48

Max. Phase current

A

2,5 … 50

Supported motor types

mm/s2

Linear-, Stepper-, Voice Coil- Servo-, DC-Motoren

Position resolution

nm

5 … 1000

Real-time trigger


Interface compatibility


Manual control units


Safety functions

Andromeda CM

Andromeda CM

Main features

  • Up to 6 axes
  • Power supply: 24 V to 48 V
  • Power: 200 W
  • Phase current: 3 A

Andromeda TT – Table version

Andromeda tt

Main features

  • 3 axis
  • DC link voltage: 24 V / 48V
  • Power: 200 W
  • Phase current: 5 A
  • Interfaces: CAN, RS232, Ethernet, USB

Andromeda Base Controller

Andromeda base

Main features

  • 2-axis
  • Power supply: 24 V / 48V
  • Power: 300 watts
  • Current in 2-phase operation: max. 10 A
  • Current in 3-phase operation: max. 5 A
  • Interfaces: CAN, RS232, Ethernet

Pollux-Controllers

Pollux

Technical Data

Parameter

Unit

Typical performance characteristics

DC link voltage

Vac

0 … 48

Max. Phase current

A

2,5 … 50

Supported motor types

mm/s2

Linear-, Stepper-, Voice Coil- Servo-, DC-Motoren

Position resolution

nm

5 … 1000

Real-time trigger


Interface compatibility


Manual control units


Safety functions

Gantry Positioning System PT15

Gantrysystem

Technical Data

Parameter

Unit

Typical performance characteristics

Travel speed in X

m/s

0.5 … 2.5

Travel speed in Y

m/s

0.5 … 0.8

Acceleration in X

m/s2

5 … 50

Acceleration in Y

m/s2

0.5 … 5

Repeatability bidirectional

µm

≤ ±0.5 … ≤ ±2.5

Positioning accuracy bidirectional

µm

≤ ±10 … ≤ ±50

Resolution

nm

50 … 500
